Tomato Tubular Preheater
- 200kgs/Hr
- SUS304 stainless steel for the main structure.
- To deactivate the pectin enzyme insides as well as soften the tomato fruits.
- To control the final product’s viscosity by controlling the heating temp.
- Product infeed and output at normal temperatures (cold break at 65-75°C, hot break at 85-100°C).
- E-mail: Angel@vortechglobal.com
- Categories: Tomato Paste Extraction and Refining Section, Tomato Processing Machine
- Inquiry Now
Product Details
The Role of the Tubular Preheater in the Tomato Paste Processing Line:
Raises the temperature of tomato juice or pulp before peeling, pulping, and refining, ensuring efficient processing and enhancing product quality by optimizing subsequent stages.
Process It Belongs To:
Extraction and Refining process, specifically before the peeling, pulping, and refining machine to prepare the tomato product for further refinement and smoother processing.
Related Equipment Before:
Crushing and Extraction Equipment – for breaking down fresh tomatoes into juice or pulp.
Juice or Pulp Conveyor – for transferring the extracted tomato juice or pulp to the preheating unit.
Related Equipment After:
Peeling Machine – for removing skins and seeds from the preheated tomato product.
Pulping and Refining Machine – for further processing the tomato product, separating impurities, and refining it into a paste.
Product Parameters:
| Model | TP-8 | YR-8 | YR-6 | YR-4 | YR-2 |
| Processing capacity | 8T/H | 6T/H | 4T/H | 2T/H | 200kG/H |
| Steam pressure MPa | 0.08-0.096 | ||||
| Discharge temperature °C | 65-100 | ||||
| Dimensions mm | Length 4060
Width 615 Height 1250 |
Length 3250
Width 615 Height 1250 |
Length 2345
Width 615 Height 1250 |
Length 1405
Width 615 Height 1250 |
Length 1000
Width 615 Height 1250 |
